- Bucket capacity0.3m³
- Power75kW
- Weight9600kg
- Dimension6500*2500*3800mm






The two-end loader is equipped with working devices at both ends, which can load and unload at both ends at the same time, reducing the number of round trips and greatly improving work efficiency. For example, at the construction site, it can load materials while unloading them to the designated location, saving a lot of time.
| Overall dimensions | 6500*2500*3800mm |
| Wheelbase | 2250mm |
| Track width | 2050mm |
| Minimum ground clearance | 400mm |
| Minimum turning radius | 4200mm |
| System pressure | 28MPa |
| Machine weight | 9600kg |
| Maximum speed | 38km/h |
| Maximum gradeability | 35° |
| Engine model | Yuchai4108Turbo |
| Rated power | 75kW |
| Rated speed | 2400r/min |
| Maximum excavation depth | 4000/5300mm |
| Maximum excavation radius | 5400/6500mm |
| Maximum lifting height | 5480/6100mm |
| Bucket capacity | 0.3m³ |
| Maximum excavation force | 46KN |
| Maximum unloading height | 2500mm |
| Maximum unloading distance | 800mm |
| Bucket capacity | 1.2m³ |
| Fuel tank | 150L |
| Hydraulic oil tank | 150L |
