LT1012 Mini Excavators
Mini But MightyThe 1200kg LT1012 PLUS mini excavator is a compact machine, capable of high performance in the most restricted areas, including within buildings and in rear gardens.
Operating Weight
1200kg
Bucket Capacity
0.022m³
Power
10HP
|
SUPPORT VARIOUSCUSTOMIZATIONSBrand/color/engine/othercustomized services, etc.We can provide you with exclusive customization services, and will produce the products you want according to your requirements, including but not limited to brand customization, color customization and engine customization. |
PRODUCT PERFORMANCEThe arm can swing left and right
Compact design giving superb performance in the most restricted areas.The left and right movement of the boom is more flexible, and the multi-angle construction is convenient and fast.
|
|
|
EASE OF USE ANDSERVICEABILITYRear bonnet can be opened The back cover is designed with a small arc to follow the shape, which complements the after-casting counterweight. It has double-sided vents, symmetrical design, and can be opened and closed at any time.Daily service checks are quick and easy to carry out. |
About accessories
-
Bucket
-
Bulldozer
-
Claw-bucket
-
Fork
Parameters of LT1012 Mini Excavators
Overall Size | |
Overall length (when transported) | 2870 mm |
Overall width (transport/work) | 930 mm |
Overall height (with/without roof) | 2285（2030）mm |
Bulldozer width | 937 mm |
Bulldozer height | 210 mm |
Track center distance | 746 mm |
Standard track shoe width | 180 mm |
Platform ground clearance | 405 mm |
Standard Bucket Width (With/Without Teeth) | 380/330 mm |
Track length | 1200 mm |
Scope Of Work | |
Maximum excavation height | 2490 mm |
Maximum unloading height | 1745 mm |
Maximum excavation depth | 1725 mm |
Maximum vertical arm digging depth | 1655 mm |
Maximum digging distance | 3030 mm |
Minimum turning radius of front end | 1490 mm |
Maximum excavation ground distance | 2940 mm |
Maximum dozing height | 170 mm |
deepest dozing height | 240 mm |
Basic Parameters | |
Operating Weight | 1200 kg |
Bucket capacity | 0.022 m3 |
Working device form | Backhoe |
Engine | |
Model | KOOP192FA |
Power | 10HP |
Maximum torque | 25/2500 N.m/r/min |
