LTZ-388
Product Details
Request Price
Attachments options make our backhoe loaders multifunctional:
Invest in what you already own - give your machine attachments and equip it to do more. And because our attachments are engineered, balanced and tested to each model, they promise to minimize stress and optimize performance.
1.who are we?
Shandong Leite Machinery Co., Ltd. is a modern international company engaged in construction machinery.
LEITE has developed rapidly by advanced technology and modern management.CE and ISO certificates areavailable.The strict quality control system and high quality production lines have developed the high quality products and fast delivery service. We have built one professional after-sales team that can server the customer well at the first time.
2.What are the advantages of our backhoe loader?
LEITE Advantages of backhoe loader: support for continuous and long-term safe engineering activities, all-terrain off-road, multi-function operations, quick attachment of accessories, excavation, crushing, trench clearing, drilling, and bulldozing.
Warranty period: within two year after delivery / 3000 working hours, if there is any quality problem, we will provide you with accessories for free.
Provide customized services, your exclusive shopping agent, personalized purchase, you are born different from others!
You know what difference about our backhoe loaders?
-Our backhoe loaders deliver the power and precise handling you need when operating in areas where using larger equipment is not practical. Because of their relatively small frame size and versatility our backhoe loaders improve construction productivity and lower your machine operating costs.
-Our backhoe loaders were designed as a system, which means every part plays a critical role.
It's why we've made it easier to maintain your machine.
-The shape of our buckets improves digging, loading and material retention.
About accessories
-
Bucket
-
Bulldozer
-
Claw-bucket
-
Fork
Parameters of LTZ-388
Overall Operating Weight | 8200KG | Rated dynamic/static Load of front axle | 7.5t/18.75t |
L*W*H (mm) | 5920×2250×3770 | Bucket Lowering Time | 3.1S |
Wheel base | 2200mm | Model | TLB1-4WD |
Min. Ground Clearance | 300mm | Type | Single-stage Three Elements |
Bucket Capacity | 1.0m3 | Max. Efficiency | 84.4% |
Breakout Force | 38KN | Inlet Pressure | 0.5Mpa |
Loading Lifting Capacity | 2500KG | Outlet Pressure | 1.1Mpa—1.3 Mpa |
Bucket Dumping Height | 2742mm | Cooling Method | Oil-cooling Pressure Circulation |
Bucket Dumping Distance | 925mm | Bucket Discharge Time | 2.0S |
Digging Depth | 52mm | Type | Fixed Shaft Power Transmission |
Backhoe Capacity | 0.3 m3 | Oil Pressure of Clutch | 1373Kpa—1569 Kpa |
Max. Digging Depth | 4082mm/4500mm | Gears | four Gears Ahead, four Gears Astern |
Swing Angle of Excavator Grab | 190o | Max. speed | 38Km/h |
Max. Pulling Force | 39KN | Model | 14-17.5/19.5L-24 |
Rated Power | 74KW | Rated Speed | 2200r/min |
Model | CUMMINS 4BTA3.9—C100 | Pressure of Front wheel | 0.55 Mpa |
Cylinder-Inside Diameter*Stroke | 4-102*120 | Displacement | 3.9L |
Min. Fuel Consumption | ≤216g/km.h | Service Brak | wet-type |
Steering Angle | ±33 o | Digging Power of Excavator Grab | 46.5KN |
Min. turning radius | 6950mm | Digging Power of Dipper | 31KN |
Pressure of the system | 12Mpa | Bucket Lifting Time | 6.8S |
